60T End Dump Trailer

60T End Dump Trailer Description:

60 Ton end dump trailer adopts high strength steel T700, offering all the durability of high-tensile-strength steel and unique structure design to maximize payload to increase your profitability.

The landing gear, Tipper Trailer adopt 28 tons of landing gear, we also have world famous brand JOST for the option.

60 Ton end dump trailer adopts Bhachu axles with 16 tons of brake pads. And other factories usually use 13 tons axles. We have more than 9 years of production experience on Bhachu axles, it has better performance on loading capacity and braking.

60T End Dump Trailer for Sale in Kenya Kisumu - Bhachu Trailer

60T End Dump Trailer for Sale in Kenya Kisumu - Bhachu Trailer

60T End Dump Trailer for Sale in Kenya Kisumu - Bhachu Trailer

Specification：

Dimension: 8000mm * 2500mm *3950m

Main beam: Height: 480mm, Upper plate: 14mm, Middle plate: 8mm, Lower plate: 14mm, Material: T700 steel.

Bottom Platform: 4 thick checkered plate

Side wall thickness: 4mm

Total volume(ton): 60ton

End plate: 8mm

Lifting System: Full set of HYVA lifting cylinder

Axle: 13T/16T, FUWA / BPW

Rim: 8.0-20 or 9.00-20

Tire: 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

ABS: Optional

Valve: WABCO valve

Light: LED light (specially intended for oversea markets)

Voltage: 24V

Tool box: 1 set

End Dump Maintenance Knowledge:

For maintenance of hoses in air brake systems and hydraulic piping systems, the following maintenance must also be performed.

1. During driving, brake hoses and high-pressure hoses in hydraulic systems,

To check whether the hose and the trailer parts are friction, pressure and so on. The above inspection must be carried out after each departure, and the hoses must be relocated and fixed immediately when found.

2. The brake hoses and hydraulic hoses must be checked frequently for rubber ageing and replaced as soon as they are found.
