150 Ton Detahcable Gooseneck Lowboy Trailer

150 Ton Detach Lowboy Trailer with Dolly Description:

Bhachu 150 ton detahcable gooseneck lowboy trailer for transport excavator and construction equipment, large machinery transportation.

the main steel type used for 150 ton detahcable gooseneck lowboy trailer is HG60. HG60 is high-strength structural steel with high toughness, good fatigue resistance, welding performance and corrosion resistance.Bhachu removable gooseneck lowboy trailer adopts reinforced the gooseneck and upper and lower plate by double layer.

Bhachu can be customized 150 ton detahcable gooseneck lowboy trailer according to actual load requirements. Common design load tonnages are 60 tons, 80 tons, 100 tons, 120 tons, 150 tons, fixed rgn equipment trailer max weight reaches 200 tons.

4 Axle 150 Ton Detahcable Gooseneck Lowboy Trailer for Sale In Kenya Mombasa | Bhachu Trailers

4 Axle 150 Ton Detahcable Gooseneck Lowboy Trailer for Sale In Kenya Mombasa | Bhachu Trailers

4 Axle 150 Ton Detahcable Gooseneck Lowboy Trailer for Sale In Kenya Mombasa | Bhachu Trailers

4 Axle 150 Ton Detahcable Gooseneck Lowboy Trailer for Sale In Kenya Mombasa | Bhachu Trailers

Specification:

Overall dimension：17900mm * 2500+250*2mm *2200mm(platform 800mm)

Loading capacity:  150 ton

Axles：4 axles with 2 axles dolly

Tire: 16 units, 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension or air suspension

Spring leaf: 120(W)mmx16(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Tare weight: About 9.5-19T

Main beam: Height: 500mm; Width: 230mm; Side beam: 250 I-beam 10/8/10; Material: HG60 high-strength steel.

Bottom Platform: 5mm thick, checkered plate

Hydraulic cylinder: 12KW diesel engine with hydraulic station

Ramp: spring or hydraulic type

ABS: Optional

Valve: WABCO valve

Light: LED light (especially intended for oversea markets)

Voltage: 24V

Toolbox: 1 set

Painting: Polyurethane paint, with long service life, and avoid the vehicle getting rust
